Description
| Brand |
| H&H Trailers |
| GVWR (lbs) |
| 14000 lbs |
| GAWR (lbs/axle) |
| 7000 lbs/axle |
| Curb Weight |
| 4550 lbs |
| Payload |
| 9450 lbs |
| Width |
| 7 |
| Length |
| 16 |
| Overall Length |
| 256 |
| Deck Width |
| 83 |
| Deck Height |
| 28.75 |
| Coupler Height |
| 12.5-20.5 |
| Gate |
| 0x0 |
| Length Deck |
| 192 |
| Length Ramp |
| 66 |
| Height Coupler |
| 12.5-20.5 |
| Height Overall |
| 58 |
| Height Deck |
| 28.75 |
| Width Interior |
| 83 |
| Width Ramp |
| 14.75 |
| Type |
| OPEN |
| 110V Electrical |
| On-Board Charger 10 Amp (110V Plug In) |
| 12V Electrical |
| 12 Volt DC 24 Battery |
| Axle |
| (2) 7000 lb. Slipper Spring Brake |
| Breakaway |
| Battery, Switch, and Lanyard |
| Connector Plug |
| Round 7-pin Blade |
| Coupler |
| 2-5/16″ Adjustable |
| Crossmembers |
| 3″ Steel Channel |
| Decking |
| 10-Gauge, One-Piece Smooth Steel |
| Exterior Finish |
| Industrial Grade Polymer Finish |
| Exterior Lights |
| Full LED, DOT Compliant |
| Exterior Storage |
| Spare Tire Carrier, Tongue Mounted Lockable Battery and Pump Box |
| Fenders |
| Double Break Tread Plate |
| Frame |
| 8″ Steel Channel |
| Hubs |
| Easy Lube |
| Hydraulic Components |
| 12 Volt Hydraulic Pump, Power Up, Power Down (Scissor Lift Hoist), Push Button Control with 15′ Lead |
| Integrated Step(s) |
| Side Steps |
| Ramp(s) |
| 4″ x 68″ Steel Ladder Style (Slide-In with Carrier) |
| Safety Chains |
| DOT Compliant |
| Sides |
| 12-Gauge, 24″ Tall |
| Tarp |
| 20′ Mesh Tarp Kit (Installed), Anti-Sail Kit with Integrated Tie-Down, Integrated Tarp Mount and Shroud, Tarp Brackets |
| Tie Downs |
| (5) 1/2″ D-Rings, Stake Pockets |
| Tires |
| ST235/80R16E 10-PR |
| Tongue |
| 6″ Steel Channel, Fully Wrapped |
| Tongue Jack |
| 12K Drop Leg, Set-Back |
| Top Rail |
| Custom Formed |
| Warranty |
| Limited 3-Year Warranty |
| Wheels |
| 16″, 8-Hole Steel |
| Wiring |
| Sealed Wiring Harness |
